Finish cover image system (#284)

* chore: bump version

* refactor: remove enableScrollButtons

* feat: handle render cases

* feat: remove links not used in properties

* test: update test vault files for cover image testing

* refactor: remove unused imports

* fix: don't show broken link when social media image isn't loaded

* feat: add image source setting app

* refactor: remove unused properties

* feat: make cover image source options draggable

* fix: prevent url's that don't have a social image from loading everytime the grid mounts

* fix: remove extra padding

* refactor: rename to social media image cache

manifest.json

@@ -1,7 +1,7 @@
 {
 	"id": "vault-explorer",
 	"name": "Vault Explorer",
-	"version": "1.36.3",
+	"version": "1.37.0",
 	"minAppVersion": "1.4.13",
 	"description": "Explore your vault in visual format",
 	"author": "DecafDev",

package.json

@@ -1,6 +1,6 @@
 {
 	"name": "obsidian-vault-explorer",
-	"version": "1.36.3",
+	"version": "1.37.0",
 	"description": "Explore your vault in visual format",
 	"main": "main.js",
 	"scripts": {

src/constants.ts

@@ -9,7 +9,7 @@ export const DEFAULT_SETTINGS: VaultExplorerPluginSettings = {
 	properties: {
 		favorite: "",
 		url: "",
-		imageUrl: "",
+		image: "",
 		createdDate: "",
 		modifiedDate: "",
 		custom1: "",
@@ -45,8 +45,25 @@ export const DEFAULT_SETTINGS: VaultExplorerPluginSettings = {
 		},
 		grid: {
 			isEnabled: true,
+			coverImageSources: [
+				{
+					type: "image-property",
+					isEnabled: true,
+				},
+				{
+					type: "url-property",
+					isEnabled: true,
+				},
+				{
+					type: "frontmatter",
+					isEnabled: true,
+				},
+				{
+					type: "body",
+					isEnabled: true,
+				},
+			],
 			loadSocialMediaImage: true,
-			coverImageSource: "frontmatter-and-body",
 		},
 		list: {
 			isEnabled: true,
@@ -74,7 +91,6 @@ export const DEFAULT_SETTINGS: VaultExplorerPluginSettings = {
 	titleWrapping: "normal",
 	enableClockUpdates: true,
 	enableFileIcons: false,
-	enableScrollButtons: true,
 	filterGroupsWidth: "300px",
 	shouldWrapFilterGroups: false,
 	pageSize: 25,

src/migrations/index.ts

@@ -26,6 +26,7 @@ import Migrate_1_29_0 from "./migrate_1_29_0";
 import Migrate_1_30_0 from "./migrate_1_30_5";
 import Migrate_1_31_0 from "./migrate_1_31_0";
 import Migrate_1_33_0 from "./migrate_1_33_0";
+import Migrate_1_37_0 from "./migrate_1_37_0";

 const migrations: TMigration[] = [
 	{
@@ -153,6 +154,11 @@ const migrations: TMigration[] = [
 		to: "1.33.0",
 		migrate: Migrate_1_33_0,
 	},
+	{
+		from: "1.36.3",
+		to: "1.37.0",
+		migrate: Migrate_1_37_0,
+	},
 ];

 export const preformMigrations = (

src/migrations/migrate_1_31_0.ts

@@ -1,11 +1,11 @@
-import { VaultExplorerPluginSettings } from "src/types";
 import MigrationInterface from "./migration_interface";
 import { VaultExplorerPluginSettings_1_30_5 } from "src/types/types-1.30.5";
+import { VaultExplorerPluginSettings_1_32_2 } from "src/types/types-1.32.2";

 export default class Migrate_1_31_0 implements MigrationInterface {
 	migrate(data: Record<string, unknown>) {
 		const typedData = data as unknown as VaultExplorerPluginSettings_1_30_5;
-		const newData: VaultExplorerPluginSettings = {
+		const newData: VaultExplorerPluginSettings_1_32_2 = {
 			...typedData,
 			shouldWrapFilterGroups: typedData.filterGroupsWrapping === "wrap",
 		};

src/migrations/migrate_1_33_0.ts

@@ -1,11 +1,11 @@
-import { VaultExplorerPluginSettings } from "src/types";
 import MigrationInterface from "./migration_interface";
 import { VaultExplorerPluginSettings_1_32_2 } from "src/types/types-1.32.2";
+import { VaultExplorerPluginSettings_1_36_3 } from "src/types/types-1.36.3";

 export default class Migrate_1_33_0 implements MigrationInterface {
 	migrate(data: Record<string, unknown>) {
 		const typedData = data as unknown as VaultExplorerPluginSettings_1_32_2;
-		const newData: VaultExplorerPluginSettings = {
+		const newData: VaultExplorerPluginSettings_1_36_3 = {
 			...typedData,
 		};


src/migrations/migrate_1_37_0.ts

@@ -0,0 +1,45 @@
+import { VaultExplorerPluginSettings } from "src/types";
+import MigrationInterface from "./migration_interface";
+import { VaultExplorerPluginSettings_1_36_3 } from "src/types/types-1.36.3";
+
+export default class Migrate_1_37_0 implements MigrationInterface {
+	migrate(data: Record<string, unknown>) {
+		const typedData = data as unknown as VaultExplorerPluginSettings_1_36_3;
+		const newData: VaultExplorerPluginSettings = {
+			...typedData,
+			views: {
+				...typedData.views,
+				grid: {
+					...typedData.views.grid,
+					coverImageSources: [
+						{
+							type: "image-property",
+							isEnabled: true,
+						},
+						{
+							type: "url-property",
+							isEnabled: true,
+						},
+						{
+							type: "frontmatter",
+							isEnabled: true,
+						},
+						{
+							type: "body",
+							isEnabled: true,
+						},
+					],
+				},
+			},
+			properties: {
+				...typedData.properties,
+				image: typedData.properties.imageUrl,
+			},
+		};
+
+		delete (newData as any).enableScrollButtons;
+		delete (newData as any).views.grid.coverImageSource;
+		delete (newData as any).properties.imageUrl;
+		return newData as unknown as Record<string, unknown>;
+	}
+}

src/obsidian/vault-explorer-settings-tab.ts

@@ -14,9 +14,10 @@ import {
 } from "src/logger/constants";
 import Logger from "js-logger";
 import { stringToLogLevel } from "src/logger";
-import { CollapseStyle, CoverImageSource, TExplorerView } from "src/types";
+import { CollapseStyle, TExplorerView } from "src/types";
 import EventManager from "src/event/event-manager";
 import LicenseKeyApp from "../svelte/license-key-app/index.svelte";
+import ImageSourceApp from "../svelte/image-source-app/index.svelte";
 import { PluginEvent } from "src/event/types";

 import "./styles.css";
@@ -24,12 +25,15 @@ import { clearSocialMediaImageCache } from "src/svelte/app/services/social-media

 export default class VaultExplorerSettingsTab extends PluginSettingTab {
 	plugin: VaultExplorerPlugin;
-	component: LicenseKeyApp | null;
+
+	licenseKeyApp: LicenseKeyApp | null;
+	imageSourceApp: ImageSourceApp | null;

 	constructor(app: App, plugin: VaultExplorerPlugin) {
 		super(app, plugin);
 		this.plugin = plugin;
-		this.component = null;
+		this.licenseKeyApp = null;
+		this.imageSourceApp = null;
 	}

 	display(): void {
@@ -97,22 +101,6 @@ export default class VaultExplorerSettingsTab extends PluginSettingTab {
 					})
 			);

-		// TODO remove?
-		// new Setting(containerEl)
-		// 	.setName("Scroll buttons")
-		// 	.setDesc("Display scroll buttons for scrollable content.")
-		// 	.addToggle((toggle) =>
-		// 		toggle
-		// 			.setValue(this.plugin.settings.enableScrollButtons)
-		// 			.onChange(async (value) => {
-		// 				this.plugin.settings.enableScrollButtons = value;
-		// 				await this.plugin.saveSettings();
-		// 				EventManager.getInstance().emit(
-		// 					"scroll-buttons-setting-change"
-		// 				);
-		// 			})
-		// 	);
-
 		new Setting(containerEl)
 			.setName("Page size")
 			.setDesc("Number of items to display per page.")
@@ -309,44 +297,9 @@ export default class VaultExplorerSettingsTab extends PluginSettingTab {

 		new Setting(containerEl).setName("Grid view").setHeading();

-		new Setting(containerEl)
-			.setName("Automatic cover image detection")
-			.setDesc("Set where cover images are automatically loaded from.")
-			.addDropdown((cb) =>
-				cb
-					.addOptions({
-						"frontmatter-and-body": "Frontmatter and body",
-						"frontmatter-only": "Frontmatter only",
-						off: "Off",
-					})
-					.setValue(this.plugin.settings.views.grid.coverImageSource)
-					.onChange(async (value) => {
-						this.plugin.settings.views.grid.coverImageSource =
-							value as CoverImageSource;
-						await this.plugin.saveSettings();
-						EventManager.getInstance().emit(
-							PluginEvent.COVER_IMAGE_SOURCE_SETTING_CHANGE
-						);
-					})
-			);
-
-		new Setting(containerEl)
-			.setName("Preferred cover image property")
-			.setDesc(
-				"If set, the value of the selected property will be preferred for the cover image"
-			)
-			.addDropdown((dropdown) =>
-				dropdown
-					.addOptions(getDropdownOptionsForProperties(textProperties))
-					.setValue(this.plugin.settings.properties.imageUrl)
-					.onChange(async (value) => {
-						this.plugin.settings.properties.imageUrl = value;
-						await this.plugin.saveSettings();
-						EventManager.getInstance().emit(
-							PluginEvent.PROPERTY_SETTING_CHANGE
-						);
-					})
-			);
+		this.imageSourceApp = new ImageSourceApp({
+			target: containerEl,
+		});

 		new Setting(containerEl)
 			.setName("Load social media image")
@@ -498,6 +451,24 @@ export default class VaultExplorerSettingsTab extends PluginSettingTab {
 					})
 			);

+		new Setting(containerEl)
+			.setName("Image property")
+			.setDesc(
+				"Property used to store an image. This must be a text property."
+			)
+			.addDropdown((dropdown) =>
+				dropdown
+					.addOptions(getDropdownOptionsForProperties(textProperties))
+					.setValue(this.plugin.settings.properties.image)
+					.onChange(async (value) => {
+						this.plugin.settings.properties.image = value;
+						await this.plugin.saveSettings();
+						EventManager.getInstance().emit(
+							PluginEvent.PROPERTY_SETTING_CHANGE
+						);
+					})
+			);
+
 		new Setting(containerEl)
 			.setName("URL property")
 			.setDesc(
@@ -645,7 +616,7 @@ export default class VaultExplorerSettingsTab extends PluginSettingTab {

 		new Setting(containerEl).setName("Premium").setHeading();

-		this.component = new LicenseKeyApp({
+		this.licenseKeyApp = new LicenseKeyApp({
 			target: containerEl,
 		});

@@ -697,7 +668,7 @@ export default class VaultExplorerSettingsTab extends PluginSettingTab {
 			);

 		new Setting(containerEl)
-			.setName("Clear cache data")
+			.setName("Social media image cache")
 			.addButton((button) =>
 				button
 					.setClass("mod-destructive")
@@ -709,7 +680,8 @@ export default class VaultExplorerSettingsTab extends PluginSettingTab {
 	}

 	onClose() {
-		this.component?.$destroy();
+		this.licenseKeyApp?.$destroy();
+		this.imageSourceApp?.$destroy();
 	}

 	private updateViewOrder(view: TExplorerView, value: boolean) {

src/svelte/app/components/grid-card.svelte

@@ -5,7 +5,7 @@
 	import store from "../../shared/services/store";
 	import Wrap from "src/svelte/shared/components/wrap.svelte";
 	import Stack from "src/svelte/shared/components/stack.svelte";
-	import { createEventDispatcher, onMount } from "svelte";
+	import { afterUpdate, createEventDispatcher, onMount } from "svelte";
 	import { WordBreak } from "src/types";
 	import { HOVER_LINK_SOURCE_ID } from "src/constants";
 	import EventManager from "src/event/event-manager";
@@ -57,24 +57,17 @@
 	let renderKey = 0;

 	onMount(() => {
-		async function updateImgSrc() {
-			if (imageUrl !== null) {
-				const entry = await getSocialMediaImageEntry(imageUrl);
-				if (entry) {
-					const isExpired =
-						await isSocialMediaImageEntryExpired(entry);
-					if (!isExpired) {
-						imgSrc = entry.socialMediaImageUrl;
-						return;
-					}
-				}
-				imgSrc = imageUrl;
-			}
-		}
-
 		updateImgSrc();
 	});

+	afterUpdate(() => {
+		if (imageUrl === null) {
+			imgSrc = null;
+		} else {
+			updateImgSrc();
+		}
+	});
+
 	onMount(() => {
 		function handleLoadSocialMediaImageChange() {
 			const newValue = plugin.settings.views.grid.loadSocialMediaImage;
@@ -128,6 +121,30 @@
 		};
 	});

+	async function updateImgSrc() {
+		if (imageUrl !== null) {
+			const entry = await getSocialMediaImageEntry(imageUrl);
+			if (entry) {
+				const isExpired = await isSocialMediaImageEntryExpired(entry);
+				if (!isExpired) {
+					const socialUrl = entry.socialMediaImageUrl;
+
+					//The url is null when the social media image does not exist
+					//This will always happen for sites like Twitter (x.com)
+					//To avoid fetching the same non-existent image, we will set imgSrc to null
+					if (socialUrl === null) {
+						imgSrc = null;
+					} else {
+						imgSrc = socialUrl;
+					}
+					return;
+				}
+			}
+			imgSrc = imageUrl;
+		}
+		console.log("Image", imageUrl, imgSrc);
+	}
+
 	function handleUrlClick(e: Event) {
 		e.stopPropagation();
 	}
@@ -181,15 +198,12 @@
 			if (socialUrl) {
 				putSocialMediaImageUrl(imgSrc, socialUrl);
 				target.src = socialUrl;
-				return;
 			} else {
-				isError = true;
+				putSocialMediaImageUrl(imgSrc, null);
 			}
 		}
 	}

-	let isError = false;
-
 	function handleImageLoad() {
 		isCoverImageLoaded = true;
 	}
@@ -219,9 +233,7 @@
 				<img
 					class="vault-explorer-grid-card__image"
 					src={imgSrc}
-					style="display: {isCoverImageLoaded || isError
-						? 'block'
-						: 'none'};"
+					style="display: {isCoverImageLoaded ? 'block' : 'none'};"
 					on:load={handleImageLoad}
 					on:error={handleImageError}
 				/>
@@ -336,11 +348,6 @@
 		border-radius: var(--radius-m);
 	}

-	/*
-	.vault-explorer-grid-card:hover {
-		background-color: var(--background-modifier-hover);
-	} */
-
 	.vault-explorer-grid-card:focus-visible {
 		box-shadow: 0 0 0 3px var(--background-modifier-border-focus);
 	}

src/svelte/app/index.svelte

@@ -10,18 +10,11 @@
 	import { Notice, TFile } from "obsidian";
 	import {
 		TCustomFilter,
-		TDashboardView,
 		TFavoritesFilter,
 		TSearchFilter,
 		TSortFilter,
 		TTimestampFilter,
 		TExplorerView,
-		TListView,
-		TGridView,
-		TRecommendedView,
-		TRelatedView,
-		TTableView,
-		TFeedView,
 	} from "src/types";
 	import store from "../shared/services/store";
 	import VaultExplorerPlugin from "src/main";
@@ -104,6 +97,7 @@

 	let frontmatterCacheTime: number = Date.now();
 	let propertySettingsTime: number = Date.now();
+	let coverImageSourcesTime: number = Date.now();

 	let loadedFiles: LoadedFile[] = [];
 	let timeValuesUpdateInterval: NodeJS.Timer | null = null;
@@ -112,43 +106,6 @@
 	let contentCache: FileContentCache = new Map();
 	let randomSortCache: RandomFileSortCache = new Map();

-	let dashboardView: TDashboardView = {
-		isEnabled: false,
-	};
-
-	let listView: TListView = {
-		isEnabled: false,
-		showTags: true,
-	};
-
-	let gridView: TGridView = {
-		loadSocialMediaImage: false,
-		isEnabled: false,
-		coverImageSource: "frontmatter-and-body",
-	};
-
-	//TODO use just isEnabled
-	let feedView: TFeedView = {
-		isEnabled: false,
-		removeH1: true,
-		lineClampSmall: 2,
-		lineClampMedium: 3,
-		lineClampLarge: 5,
-		collapseStyle: "no-new-lines",
-	};
-
-	let tableView: TTableView = {
-		isEnabled: false,
-	};
-
-	let recommendedView: TRecommendedView = {
-		isEnabled: false,
-	};
-
-	let relatedView: TRelatedView = {
-		isEnabled: false,
-	};
-
 	let viewOrder: TExplorerView[] = [];

 	// ============================================
@@ -181,13 +138,6 @@
 		timestampFilter = settings.filters.timestamp;
 		currentView = settings.currentView;
 		customFilter = settings.filters.custom;
-		dashboardView = settings.views.dashboard;
-		listView = settings.views.list;
-		gridView = settings.views.grid;
-		feedView = settings.views.feed;
-		tableView = settings.views.table;
-		recommendedView = settings.views.recommended;
-		relatedView = settings.views.related;
 		viewOrder = settings.viewOrder;

 		if (settings.enableClockUpdates) {
@@ -501,8 +451,7 @@
 				message: "called",
 			});

-			//TODO update?
-			updateFrontmatterCacheTime();
+			coverImageSourcesTime = Date.now();
 		}

 		EventManager.getInstance().on(
@@ -567,13 +516,6 @@
 		plugin.settings.filters.sort = sortFilter;
 		plugin.settings.filters.timestamp = timestampFilter;
 		plugin.settings.filters.favorites = favoritesFilter;
-		plugin.settings.views.dashboard = dashboardView;
-		plugin.settings.views.list = listView;
-		plugin.settings.views.grid = gridView;
-		plugin.settings.views.feed = feedView;
-		plugin.settings.views.table = tableView;
-		plugin.settings.views.recommended = recommendedView;
-		plugin.settings.views.related = relatedView;
 		plugin.settings.currentView = currentView;
 		plugin.settings.filters.custom = customFilter;
 		plugin.settings.viewOrder = viewOrder;
@@ -799,7 +741,7 @@
 	}

 	let formatted: FileRenderData[] = [];
-	$: if (propertySettingsTime) {
+	$: if (propertySettingsTime || coverImageSourcesTime) {
 		formatted = filteredCustom.map((loadedFile) => {
 			const { id, file } = loadedFile;
 			const frontmatter =
@@ -882,13 +824,6 @@
 		favoritesFilter,
 		currentView,
 		customFilter,
-		dashboardView,
-		listView,
-		gridView,
-		feedView,
-		tableView,
-		recommendedView,
-		relatedView,
 		viewOrder,
 		saveSettings();


src/svelte/app/services/render-data.ts

@@ -14,17 +14,16 @@ import {
 import { isImageExtension } from "./utils/image-utils";
 import { removeFrontmatter } from "./utils/content-utils";
 import { getURIForWikiLinkTarget } from "./utils/wiki-link-utils";
-import {
-	isExternalEmbed,
-	isInternalEmbed,
-	isUrl,
-	isWikiLink,
-} from "./link-utils/link-validators";
+import { isUrl, isWikiLink } from "./link-utils/link-validators";
 import {
 	getExternalEmbedTarget,
 	getInternalEmbedTarget,
 	getWikiLinkTarget,
 } from "./link-utils/link-target-getters";
+import {
+	getFirstExternalEmbed,
+	getFirstInternalEmbed,
+} from "./link-utils/link-getters";

 /**
  * Formats the file's data for rendering
@@ -56,12 +55,12 @@ export const formatFileDataForRender = ({
 }): FileRenderData => {
 	const { name, basename, extension, path } = file;

-	const { coverImageSource } = settings.views.grid;
+	const { coverImageSources } = settings.views.grid;
 	const {
 		createdDate: createdDateProp,
 		modifiedDate: modifiedDateProp,
 		url: urlProp,
-		imageUrl: imageUrlProp,
+		image: imageProp,
 		favorite: favoriteProp,
 		custom1: custom1Prop,
 		custom2: custom2Prop,
@@ -149,58 +148,62 @@ export const formatFileDataForRender = ({
 		imageUrl = app.vault.getResourcePath(file);
 	}

-	//Handle image property
-	if (imageUrl === null && coverImageSource !== "off") {
-		const loadedUrl = loadPropertyValue<string>(
-			fileFrontmatter,
-			imageUrlProp,
-			PropertyType.TEXT
-		);
-
-		if (loadedUrl !== null) {
-			if (isInternalEmbed(loadedUrl)) {
-				const target = getInternalEmbedTarget(loadedUrl);
-				if (target) {
-					const uri = getURIForWikiLinkTarget(app, target, path);
-					if (uri) {
-						imageUrl = uri;
+	for (const imageSource of coverImageSources) {
+		const { type, isEnabled } = imageSource;
+		if (isEnabled) {
+			switch (type) {
+				case "image-property": {
+					const loadedUrl = handleImagePropertyCoverSource(
+						app,
+						fileFrontmatter,
+						path,
+						imageProp
+					);
+					if (loadedUrl !== null) {
+						imageUrl = loadedUrl;
 					}
+					break;
 				}
-			} else if (isWikiLink(loadedUrl)) {
-				const target = getWikiLinkTarget(loadedUrl);
-				if (target) {
-					const uri = getURIForWikiLinkTarget(app, target, path);
-					if (uri) {
-						imageUrl = uri;
+				case "url-property": {
+					const loadedUrl = handleUrlPropertyCoverSource(
+						fileFrontmatter,
+						urlProp
+					);
+					if (loadedUrl !== null) {
+						imageUrl = loadedUrl;
 					}
+					break;
 				}
-			} else if (isExternalEmbed(loadedUrl)) {
-				const target = getExternalEmbedTarget(loadedUrl);
-				if (target) {
-					imageUrl = target;
+				case "frontmatter": {
+					const loadedUrl = handleFrontmatterCoverSource(
+						app,
+						fileFrontmatter,
+						path
+					);
+					if (loadedUrl !== null) {
+						imageUrl = loadedUrl;
+					}
+					break;
 				}
-			} else if (isUrl(loadedUrl)) {
-				imageUrl = loadedUrl;
+				case "body": {
+					const loadedUrl = handleBodyCoverSource(
+						app,
+						path,
+						fileContent
+					);
+					if (loadedUrl !== null) {
+						imageUrl = loadedUrl;
+					}
+					break;
+				}
+				default:
+					throw new Error(
+						`Unhandled cover image source type: ${type}`
+					);
+			}
+			if (imageUrl !== null) {
+				break; // Exit the loop if a non-null URL is found
 			}
-		}
-	}
-
-	//Handle image in frontmatter
-	if (imageUrl === null && coverImageSource !== "off") {
-		const textProperties: FileTextProperties = loadTextProperties(
-			app,
-			fileFrontmatter
-		);
-
-		for (const property of textProperties) {
-			//TODO implement
-		}
-	}
-
-	if (imageUrl === null && coverImageSource === "frontmatter-and-body") {
-		if (fileContent !== null) {
-			const body = removeFrontmatter(fileContent);
-			//TODO implement
 		}
 	}

@@ -224,3 +227,105 @@ export const formatFileDataForRender = ({
 		custom3,
 	};
 };
+
+const handleImagePropertyCoverSource = (
+	app: App,
+	fileFrontmatter: FrontMatterCache | undefined,
+	filePath: string,
+	imageProperty: string
+) => {
+	const propertyValue = loadPropertyValue<string>(
+		fileFrontmatter,
+		imageProperty,
+		PropertyType.TEXT
+	);
+	return getImageUrlFromProperty(app, filePath, propertyValue);
+};
+
+const handleUrlPropertyCoverSource = (
+	fileFrontmatter: FrontMatterCache | undefined,
+	urlProperty: string
+) => {
+	const propertyValue = loadPropertyValue<string>(
+		fileFrontmatter,
+		urlProperty,
+		PropertyType.TEXT
+	);
+	if (propertyValue !== null) {
+		if (isUrl(propertyValue)) {
+			return propertyValue;
+		}
+	}
+	return null;
+};
+
+const handleFrontmatterCoverSource = (
+	app: App,
+	fileFrontmatter: FrontMatterCache | undefined,
+	filePath: string
+) => {
+	const textProperties: FileTextProperties = loadTextProperties(
+		app,
+		fileFrontmatter
+	);
+
+	for (const property of textProperties) {
+		const { value } = property;
+		const imageUrl = getImageUrlFromProperty(app, filePath, value);
+		if (imageUrl) {
+			return imageUrl;
+		}
+	}
+	return null;
+};
+
+const handleBodyCoverSource = (
+	app: App,
+	filePath: string,
+	fileContent: string | null
+) => {
+	if (fileContent === null) return null;
+
+	const body = removeFrontmatter(fileContent);
+	const firstInternalLink = getFirstInternalEmbed(body);
+	if (firstInternalLink) {
+		const target = getInternalEmbedTarget(firstInternalLink);
+		if (target) {
+			const uri = getURIForWikiLinkTarget(app, target, filePath);
+			if (uri) {
+				return uri;
+			}
+		}
+	}
+
+	const firstExternalLink = getFirstExternalEmbed(body);
+	if (firstExternalLink) {
+		const target = getExternalEmbedTarget(firstExternalLink);
+		if (target) {
+			return target;
+		}
+	}
+
+	return null;
+};
+
+const getImageUrlFromProperty = (
+	app: App,
+	filePath: string,
+	propertyValue: string | null
+) => {
+	if (propertyValue === null) return null;
+
+	if (isWikiLink(propertyValue)) {
+		const target = getWikiLinkTarget(propertyValue);
+		if (target) {
+			const uri = getURIForWikiLinkTarget(app, target, filePath);
+			if (uri) {
+				return uri;
+			}
+		}
+	} else if (isUrl(propertyValue)) {
+		return propertyValue;
+	}
+	return null;
+};

src/svelte/app/services/social-media-image-cache.ts

@@ -9,7 +9,7 @@ const ENTRY_EXPIRATION_TIME = ONE_WEEK_MILLIS;

 interface SocialMediaImageEntry {
 	url: string;
-	socialMediaImageUrl: string;
+	socialMediaImageUrl: string | null; // null if no social media image found
 	timestamp: number;
 }

@@ -42,7 +42,7 @@ export const getSocialMediaImageEntry = async (url: string) => {
  */
 export const putSocialMediaImageUrl = async (
 	url: string,
-	socialMediaImageUrl: string
+	socialMediaImageUrl: string | null
 ) => {
 	const db = await openDatabase();
 	db.put(STORE_NAME, {

src/svelte/image-source-app/display-name.ts

@@ -0,0 +1,16 @@
+import { CoverImageSourceType } from "src/types";
+
+export const getDisplayNameForImageSource = (type: CoverImageSourceType) => {
+	switch (type) {
+		case "image-property":
+			return "Image Property";
+		case "url-property":
+			return "URL";
+		case "frontmatter":
+			return "Frontmatter";
+		case "body":
+			return "Body";
+		default:
+			return "";
+	}
+};

src/svelte/image-source-app/index.svelte

@@ -0,0 +1,129 @@
+<script lang="ts">
+	import store from "../shared/services/store";
+	import VaultExplorerPlugin from "src/main";
+	import { CoverImageSource, CoverImageSourceType } from "src/types";
+	import { getDisplayNameForImageSource } from "./display-name";
+	import Icon from "../shared/components/icon.svelte";
+	import { PluginEvent } from "src/event/types";
+	import EventManager from "src/event/event-manager";
+
+	let plugin: VaultExplorerPlugin | null = null;
+	let coverImageSources: CoverImageSource[] = [];
+
+	store.plugin.subscribe((p) => {
+		plugin = p;
+		coverImageSources = p.settings.views.grid.coverImageSources;
+	});
+
+	function handleSourceClick(type: CoverImageSourceType) {
+		const updatedSources = coverImageSources.map((source) => {
+			if (source.type === type) {
+				return {
+					...source,
+					isEnabled: !source.isEnabled,
+				};
+			}
+			return source;
+		});
+		coverImageSources = updatedSources;
+	}
+
+	async function saveSettings() {
+		if (!plugin) return;
+
+		plugin.settings.views.grid.coverImageSources = coverImageSources;
+		await plugin.saveSettings();
+		EventManager.getInstance().emit(
+			PluginEvent.COVER_IMAGE_SOURCE_SETTING_CHANGE,
+		);
+	}
+
+	function handleSourceDragOver(e: Event) {
+		e.preventDefault();
+	}
+
+	function handleSourceDragStart(e: Event, type: CoverImageSourceType) {
+		(e as any).dataTransfer.setData("text", type);
+		(e as any).dataTransfer.effectAllowed = "move";
+	}
+
+	function handleSourceDrop(e: Event, id: string) {
+		const dragId = (e as any).dataTransfer.getData("text");
+		(e as any).dataTransfer.dropEffect = "move";
+
+		const draggedIndex = coverImageSources.findIndex(
+			(source) => source.type === dragId,
+		);
+		const dragged = coverImageSources.find(
+			(source) => source.type === dragId,
+		);
+
+		const droppedIndex = coverImageSources.findIndex(
+			(source) => source.type === id,
+		);
+		const dropped = coverImageSources.find((source) => source.type === id);
+
+		if (!dragged || !dropped || draggedIndex === -1 || droppedIndex === -1)
+			return;
+
+		let newCoverImageSources = [...coverImageSources];
+		newCoverImageSources[draggedIndex] = dropped;
+		newCoverImageSources[droppedIndex] = dragged;
+		coverImageSources = newCoverImageSources;
+	}
+
+	$: coverImageSources, saveSettings();
+</script>
+
+<div class="setting-item">
+	<div class="setting-item-info">
+		<div class="setting-item-name">Image source</div>
+		<div class="setting-item-description">
+			<div class="vault-explorer-image-source-setting-container">
+				{#each coverImageSources as source}
+					<div
+						tabindex="0"
+						role="button"
+						draggable="true"
+						on:dragstart={(e) =>
+							handleSourceDragStart(e, source.type)}
+						on:dragover={handleSourceDragOver}
+						on:drop={(e) => handleSourceDrop(e, source.type)}
+						class="vault-explorer-image-source-setting-row"
+						on:click={() => handleSourceClick(source.type)}
+						on:keydown={(e) => {
+							if (e.key === "Enter" || e.key === " ") {
+								handleSourceClick(source.type);
+							}
+						}}
+					>
+						<div class="vault-explorer-image-source-setting-title">
+							<Icon iconId={source.isEnabled ? "check" : "x"} />
+							<div>
+								{getDisplayNameForImageSource(source.type)}
+							</div>
+						</div>
+						<Icon iconId="grip-horizontal" />
+					</div>
+				{/each}
+			</div>
+		</div>
+	</div>
+</div>
+
+<style>
+	.vault-explorer-image-source-setting-title {
+		display: flex;
+		column-gap: 8px;
+	}
+
+	.vault-explorer-image-source-setting-row {
+		display: flex;
+		justify-content: space-between;
+		padding: 8px 8px;
+	}
+
+	.vault-explorer-image-source-setting-row:hover {
+		background-color: var(--background-modifier-hover);
+	}
+</style>

src/svelte/license-key-app/index.svelte

@@ -117,9 +117,6 @@
 <style>
 	.vault-explorer-setting-message {
 		color: var(--text-muted);
-		font-size: var(--font-smallest);
-		padding-top: var(--size-4-1);
-		line-height: var(--line-height-tight);
 	}

 	.vault-explorer-setting-message--success {

src/types/index.guard.ts

@@ -15,7 +15,7 @@ export function isVaultExplorerPluginSettings(obj: unknown): obj is VaultExplore
             typeof typedObj["properties"] === "function") &&
         typeof typedObj["properties"]["favorite"] === "string" &&
         typeof typedObj["properties"]["url"] === "string" &&
-        typeof typedObj["properties"]["imageUrl"] === "string" &&
+        typeof typedObj["properties"]["image"] === "string" &&
         typeof typedObj["properties"]["createdDate"] === "string" &&
         typeof typedObj["properties"]["modifiedDate"] === "string" &&
         typeof typedObj["properties"]["custom1"] === "string" &&
@@ -595,9 +595,17 @@ export function isVaultExplorerPluginSettings(obj: unknown): obj is VaultExplore
             typeof typedObj["views"]["grid"] === "object" ||
             typeof typedObj["views"]["grid"] === "function") &&
         typeof typedObj["views"]["grid"]["isEnabled"] === "boolean" &&
-        (typedObj["views"]["grid"]["coverImageSource"] === "frontmatter-only" ||
-            typedObj["views"]["grid"]["coverImageSource"] === "frontmatter-and-body" ||
-            typedObj["views"]["grid"]["coverImageSource"] === "off") &&
+        Array.isArray(typedObj["views"]["grid"]["coverImageSources"]) &&
+        typedObj["views"]["grid"]["coverImageSources"].every((e: any) =>
+            (e !== null &&
+                typeof e === "object" ||
+                typeof e === "function") &&
+            (e["type"] === "image-property" ||
+                e["type"] === "url-property" ||
+                e["type"] === "frontmatter" ||
+                e["type"] === "body") &&
+            typeof e["isEnabled"] === "boolean"
+        ) &&
         typeof typedObj["views"]["grid"]["loadSocialMediaImage"] === "boolean" &&
         (typedObj["views"]["list"] !== null &&
             typeof typedObj["views"]["list"] === "object" ||
@@ -638,7 +646,6 @@ export function isVaultExplorerPluginSettings(obj: unknown): obj is VaultExplore
             typedObj["currentView"] === TExplorerView.TABLE ||
             typedObj["currentView"] === TExplorerView.RECOMMENDED ||
             typedObj["currentView"] === TExplorerView.RELATED) &&
-        typeof typedObj["enableScrollButtons"] === "boolean" &&
         typeof typedObj["pageSize"] === "number" &&
         typeof typedObj["filterGroupsWidth"] === "string" &&
         typeof typedObj["shouldWrapFilterGroups"] === "boolean" &&

src/types/index.ts

@@ -3,7 +3,7 @@ export interface VaultExplorerPluginSettings {
 	properties: {
 		favorite: string;
 		url: string;
-		imageUrl: string;
+		image: string;
 		createdDate: string;
 		modifiedDate: string;
 		custom1: string;
@@ -30,7 +30,6 @@ export interface VaultExplorerPluginSettings {
 	enableClockUpdates: boolean;
 	enableFileIcons: boolean;
 	currentView: TExplorerView | null;
-	enableScrollButtons: boolean;
 	pageSize: number;
 	filterGroupsWidth: string;
 	shouldWrapFilterGroups: boolean;
@@ -53,14 +52,20 @@ export interface TListView extends BaseView {
 }

 export interface TGridView extends BaseView {
-	coverImageSource: CoverImageSource;
+	coverImageSources: CoverImageSource[];
 	loadSocialMediaImage: boolean;
 }

-export type CoverImageSource =
-	| "frontmatter-only"
-	| "frontmatter-and-body"
-	| "off";
+export interface CoverImageSource {
+	type: CoverImageSourceType;
+	isEnabled: boolean;
+}
+
+export type CoverImageSourceType =
+	| "image-property"
+	| "url-property"
+	| "frontmatter"
+	| "body";

 export interface TDashboardView extends BaseView {}


src/types/types-1.36.3.ts

@@ -0,0 +1,318 @@
+export interface VaultExplorerPluginSettings_1_36_3 {
+	properties: {
+		favorite: string;
+		url: string;
+		imageUrl: string;
+		createdDate: string;
+		modifiedDate: string;
+		custom1: string;
+		custom2: string;
+		custom3: string;
+	};
+	filters: {
+		search: TSearchFilter;
+		favorites: TFavoritesFilter;
+		sort: TSortFilter;
+		timestamp: TTimestampFilter;
+		custom: TCustomFilter;
+	};
+	views: {
+		dashboard: TDashboardView;
+		grid: TGridView;
+		list: TListView;
+		table: TTableView;
+		feed: TFeedView;
+		recommended: TRecommendedView;
+		related: TRelatedView;
+	};
+	titleWrapping: WordBreak;
+	enableClockUpdates: boolean;
+	enableFileIcons: boolean;
+	currentView: TExplorerView | null;
+	enableScrollButtons: boolean;
+	pageSize: number;
+	filterGroupsWidth: string;
+	shouldWrapFilterGroups: boolean;
+	viewOrder: TExplorerView[];
+	configDir: string;
+	pluginVersion: string | null;
+	logLevel: string;
+}
+
+type FileInteractionStyle = "title" | "content";
+
+interface BaseView {
+	isEnabled: boolean;
+}
+
+interface TTableView extends BaseView {}
+
+interface TListView extends BaseView {
+	showTags: boolean;
+}
+
+interface TGridView extends BaseView {
+	coverImageSource: CoverImageSource;
+	loadSocialMediaImage: boolean;
+}
+
+type CoverImageSource = "frontmatter-only" | "frontmatter-and-body" | "off";
+
+interface TDashboardView extends BaseView {}
+
+type CollapseStyle = "no-new-lines" | "no-extra-new-lines";
+
+interface TFeedView extends BaseView {
+	collapseStyle: CollapseStyle;
+	removeH1: boolean;
+	lineClampSmall: number;
+	lineClampMedium: number;
+	lineClampLarge: number;
+}
+
+interface TRecommendedView extends BaseView {}
+
+interface TRelatedView extends BaseView {}
+
+interface BaseFilter {
+	isEnabled: boolean;
+}
+
+interface TSearchFilter extends BaseFilter {
+	value: string;
+}
+
+interface TFavoritesFilter extends BaseFilter {
+	value: boolean;
+}
+
+interface TSortFilter extends BaseFilter {
+	value: SortFilterOption;
+}
+
+interface TTimestampFilter extends BaseFilter {
+	value: TimestampFilterOption;
+}
+
+interface TCustomFilter extends BaseFilter {
+	selectedGroupId: string;
+	groups: TFilterGroup[];
+}
+
+type TimestampFilterOption =
+	| "created-today"
+	| "modified-today"
+	| "created-this-week"
+	| "modified-this-week"
+	| "created-2-weeks"
+	| "modified-2-weeks"
+	| "all";
+
+type SortFilterOption =
+	| "file-name-asc"
+	| "file-name-desc"
+	| "modified-asc"
+	| "modified-desc"
+	| "random";
+
+type WordBreak = "normal" | "break-word";
+
+enum TExplorerView {
+	DASHBOARD = "dashboard",
+	GRID = "grid",
+	LIST = "list",
+	FEED = "feed",
+	TABLE = "table",
+	RECOMMENDED = "recommended",
+	RELATED = "related",
+}
+
+type FilterOperator = "and" | "or";
+
+enum TextFilterCondition {
+	IS = "is",
+	IS_NOT = "is-not",
+	CONTAINS = "contains",
+	DOES_NOT_CONTAIN = "does-not-contain",
+	STARTS_WITH = "starts-with",
+	ENDS_WITH = "ends-with",
+	EXISTS = "exists",
+	DOES_NOT_EXIST = "does-not-exist",
+}
+
+enum ListFilterCondition {
+	CONTAINS = "contains",
+	DOES_NOT_CONTAIN = "does-not-contain",
+	EXISTS = "exists",
+	DOES_NOT_EXIST = "does-not-exist",
+}
+
+enum NumberFilterCondition {
+	IS_EQUAL = "is-equal",
+	IS_NOT_EQUAL = "is-not-equal",
+	IS_GREATER = "is-greater",
+	IS_LESS = "is-less",
+	IS_GREATER_OR_EQUAL = "is-greater-or-equal",
+	IS_LESS_OR_EQUAL = "is-less-or-equal",
+	EXISTS = "exists",
+	DOES_NOT_EXIST = "does-not-exist",
+}
+
+enum CheckboxFilterCondition {
+	IS = "is",
+	IS_NOT = "is-not",
+	EXISTS = "exists",
+	DOES_NOT_EXIST = "does-not-exist",
+}
+
+enum DateFilterCondition {
+	IS = "is",
+	IS_BEFORE = "is-before",
+	IS_AFTER = "is-after",
+	IS_ON_OR_BEFORE = "is-on-or-before",
+	IS_ON_OR_AFTER = "is-on-or-after",
+	EXISTS = "exists",
+	DOES_NOT_EXIST = "does-not-exist",
+}
+
+enum ContentFilterCondition {
+	CONTAINS = "contains",
+	DOES_NOT_CONTAIN = "does-not-contain",
+	IS_EMPTY = "is-empty",
+	IS_NOT_EMPTY = "is-not-empty",
+}
+
+enum FolderFilterCondition {
+	IS = "is",
+	IS_NOT = "is-not",
+}
+
+enum FileNameFilterCondition {
+	IS = "is",
+	IS_NOT = "is-not",
+	CONTAINS = "contains",
+	DOES_NOT_CONTAIN = "does-not-contain",
+	STARTS_WITH = "starts-with",
+	ENDS_WITH = "ends-with",
+}
+
+type FilterCondition =
+	| TextFilterCondition
+	| NumberFilterCondition
+	| DateFilterCondition
+	| CheckboxFilterCondition
+	| ListFilterCondition
+	| ContentFilterCondition
+	| FolderFilterCondition
+	| FileNameFilterCondition;
+
+//This matches the Obsidian property types
+enum PropertyType {
+	TEXT = "text",
+	NUMBER = "number",
+	LIST = "list",
+	CHECKBOX = "checkbox",
+	DATE = "date",
+	DATETIME = "datetime",
+}
+
+enum FilterRuleType {
+	PROPERTY = "property",
+	FOLDER = "folder",
+	FILE_NAME = "file-name",
+	CONTENT = "content",
+}
+
+enum DatePropertyFilterValue {
+	TODAY = "today",
+	TOMORROW = "tomorrow",
+	YESTERDAY = "yesterday",
+	ONE_WEEK_FROM_NOW = "one-week-from-now",
+	ONE_WEEK_AGO = "one-week-ago",
+	ONE_MONTH_FROM_NOW = "one-month-from-now",
+	ONE_MONTH_AGO = "one-month-ago",
+	CUSTOM = "custom",
+}
+
+interface BaseFilterRule {
+	id: string;
+	operator: FilterOperator;
+	type: FilterRuleType;
+	condition: FilterCondition;
+	isEnabled: boolean;
+	value: string;
+	matchWhenPropertyDNE: boolean;
+}
+
+interface TextPropertyFilterRule extends BaseFilterRule {
+	type: FilterRuleType.PROPERTY;
+	propertyType: PropertyType.TEXT;
+	propertyName: string;
+	condition: TextFilterCondition;
+}
+
+interface NumberPropertyFilterRule extends BaseFilterRule {
+	type: FilterRuleType.PROPERTY;
+	propertyType: PropertyType.NUMBER;
+	propertyName: string;
+	condition: NumberFilterCondition;
+}
+
+interface ListPropertyFilterRule extends BaseFilterRule {
+	type: FilterRuleType.PROPERTY;
+	propertyType: PropertyType.LIST;
+	propertyName: string;
+	condition: ListFilterCondition;
+}
+
+interface CheckboxPropertyFilterRule extends BaseFilterRule {
+	type: FilterRuleType.PROPERTY;
+	propertyType: PropertyType.CHECKBOX;
+	propertyName: string;
+	condition: CheckboxFilterCondition;
+}
+
+interface DatePropertyFilterRule extends BaseFilterRule {
+	type: FilterRuleType.PROPERTY;
+	propertyType: PropertyType.DATE | PropertyType.DATETIME;
+	propertyName: string;
+	condition: DateFilterCondition;
+	valueData: string;
+}
+
+interface FolderFilterRule extends BaseFilterRule {
+	type: FilterRuleType.FOLDER;
+	condition: FolderFilterCondition;
+	includeSubfolders: boolean;
+}
+
+interface FileNameFilterRule extends BaseFilterRule {
+	type: FilterRuleType.FILE_NAME;
+	condition: FileNameFilterCondition;
+}
+
+interface ContentFilterRule extends BaseFilterRule {
+	type: FilterRuleType.CONTENT;
+	condition: ContentFilterCondition;
+}
+
+type TFilterRule =
+	| PropertyFilterRule
+	| FolderFilterRule
+	| FileNameFilterRule
+	| ContentFilterRule;
+
+type PropertyFilterRule =
+	| TextPropertyFilterRule
+	| NumberPropertyFilterRule
+	| ListPropertyFilterRule
+	| CheckboxPropertyFilterRule
+	| DatePropertyFilterRule;
+
+interface TFilterGroup {
+	id: string;
+	name: string;
+	rules: TFilterRule[];
+	isEnabled: boolean;
+	isSticky: boolean;
+}

test-vault/.obsidian/plugins/vault-explorer/data.json

@@ -8,7 +8,7 @@
     "creationDate": "creation",
     "modifiedDate": "modification",
     "createdDate": "creation",
-    "imageUrl": "image"
+    "image": "image"
   },
   "filters": {
     "search": {
@@ -51,7 +51,24 @@
     "grid": {
       "isEnabled": true,
       "loadSocialMediaImage": true,
-      "coverImageSource": "frontmatter-and-body"
+      "coverImageSources": [
+        {
+          "type": "image-property",
+          "isEnabled": true
+        },
+        {
+          "type": "url-property",
+          "isEnabled": true
+        },
+        {
+          "type": "frontmatter",
+          "isEnabled": true
+        },
+        {
+          "type": "body",
+          "isEnabled": true
+        }
+      ]
     },
     "list": {
       "isEnabled": true,
@@ -82,7 +99,6 @@
   "titleWrapping": "normal",
   "enableClockUpdates": true,
   "enableFileIcons": true,
-  "enableScrollButtons": true,
   "filterGroupsWidth": "759px",
   "shouldWrapFilterGroups": false,
   "pageSize": 25,
@@ -92,6 +108,6 @@
     "feed"
   ],
   "configDir": ".vaultexplorer",
-  "pluginVersion": "1.36.2",
+  "pluginVersion": "1.37.0",
   "logLevel": "trace"
 }

test-vault/Content with external embed.md

@@ -1,2 +1 @@
-![cover](https://plus.unsplash.com/premium_photo-1721926057308-2aa7ce470776?q=80&w=2940&auto=format&fit=crop&ixlib=rb-4.0.3&ixid=M3wxMjA3fDB8MHxwaG90by1wYWdlfHx8fGVufDB8fHx8fA%3D%3D)
-
+![cover](https://plus.unsplash.com/premium_photo-1721926057308-2aa7ce470776?q=80&w=2940&auto=format&fit=crop&ixlib=rb-4.0.3&ixid=M3wxMjA3fDB8MHxwaG90by1wYWdlfHx8fGVufDB8fHx8fA%3D%3D)

test-vault/Frontmatter with banner and image.md

@@ -1,4 +0,0 @@
----
-banner: "[[pexels-tomfisk-1653823.jpg]]"
-image:
----

test-vault/Frontmatter with banner and url.md

@@ -1,4 +0,0 @@
----
-banner: "[[pexels-tomfisk-1653823.jpg]]"
-url: https://vaultexplorer.com
----

test-vault/Frontmatter with embed image.md

@@ -0,0 +1,3 @@
+---
+image: "![[pexels-tomfisk-1653823.jpg]]"
+---

test-vault/Frontmatter with image (url).md

@@ -0,0 +1,3 @@
+---
+image: https://vaultexplorer.com
+---

test-vault/Frontmatter with image (wiki link).md

@@ -0,0 +1,3 @@
+---
+image: "[[pexels-tomfisk-1653823.jpg]]"
+---

test-vault/Frontmatter with image.md

@@ -1,4 +0,0 @@
----
-image: "[[pexels-kelly-1179532-23732393.jpg]]"
-favorite: false
----

test-vault/Frontmatter with url and banner.md

@@ -1,4 +0,0 @@
----
-url: https://vaultexplorer.com
-banner: "[[pexels-tomfisk-1653823.jpg]]"
----

test-vault/Frontmatter with url.md

@@ -0,0 +1,3 @@
+---
+url: https://vaultexplorer.com
+---

versions.json

@@ -126,5 +126,6 @@
 	"1.36.0": "1.4.13",
 	"1.36.1": "1.4.13",
 	"1.36.2": "1.4.13",
-	"1.36.3": "1.4.13"
+	"1.36.3": "1.4.13",
+	"1.37.0": "1.4.13"
 }
